BP87213

The BP87213 is a highlyintegrated current mode PWMswitcher lC with high performance, low standbyconsumption suitable for designing flyback converters. The BP87213 integrate a 650 V power MOSFET and a high-voltage current source which eliminates the startupresistors. lt supports CCM and DCM operations. At fullload, the lC operates in 65 kHz fixed frequency.

Less than 75 mW no-load consumption

Integrated 650 V power MOSFET

High-voltage current source eliminates startup resistors

Accurate primary-side const power control

Internal 4ms soft start

• QC/USB PD Chargers
• AC/DC Adapters
• Standby Power supply

•
